Products with ELD "SWITCH"
Below you will find a list of products with the ELD "" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufactorer, as well as contact information for further troubleshooting.
Switchboard
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | Switchboard | SB1 | 1.27 or above |
Data Transfer and Reporting Procedures
> Telematic (Web Service, Email)Malfunctions and Testing
On the Switchboard ELD device, select the "Authority" button on the driver screen. In this "Authority View", regulators can view the hours-of-service logs for the driver. In addition to viewing the hours-of-service graph, ELD Events, Malfunction recordings, Switchboard's Electronic Logging Devices have the following methods to transfer hours-of-service data over to authorities and regulators: 1. Faxing Logs to a Fax Number By selecting "Share Logs" on the top right of the "Authority View", one can select the "Fax" option and enter a fax number to send the last 7 to 14 days of logs to. 2. Email Transfer By selecting "Share Logs" on the top right of the "Authority View", one can select the "Email" option and enter an email address to send the last 7 to 14 days of logs to. 3. Wireless Web Services When the FMCSA has set up its server to be able to send the Hours-of-Service logs, Switchboard has the appropriate processes to send driver log data to the servers ready to go. When sending the logs via fax or email, the data should be sent instantly. If the tablet is outside of data coverage, log data should be sent once the tablet obtains data coverage.Certification Statement
The user can view the summary of malfunctions through the "Authority View" on the Switchboard Electronic Logging Device. On the Switchboard ELD device, select the "Authority" button on the driver screen. There you will be able to see your ELD Events (Duty Status Changes, Malfunctions, Login/Logout Events, Engine Events). To see more details regarding the malfunctions, select "View Malfunctions" to view the list of ELD Malfunction records. On the list of the malfunctions, you will see the Date/Time of the malfunction, the malfunction code as well as the malfunction description.
User Manual:
Switchboard ELD Manual.pdf
