Products with ELD "URS138"
Below you will find a list of products with the ELD "" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufactorer, as well as contact information for further troubleshooting.
UNITY ELD
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | UNITY ELD | URS | 2.0 or higher |
Data Transfer and Reporting Procedures
>Malfunctions and Testing
UNITY ELD is capable of producing and transferring the ELD records via telematics transfer methods: Wireless Web services and Email. In order to send the ELD records via Web services, a driver must press “DOT Inspection” menu item, then press “Send Logs” button, select Web Service as the Data Transfer Type and press “SEND” button. In order to send the ELD records via Email, a driver must press “DOT Inspection” menu item, then press “Send Logs” button, select Email as the Data Transfer Type and press “SEND” button.Certification Statement
UNITY ELD monitors its compliance with the technical requirements and detects malfunctions and data inconsistencies and keeps records of its malfunction and data diagnostic event detection. Following standard coding is implemented for required compliance malfunction and data diagnostic event detection: P - “Power compliance” malfunction, E - “Engine synchronization compliance” malfunction, T - “Timing compliance” malfunction, L - “Positioning compliance” malfunction, R - “Data recording compliance” malfunction, S - “Data transfer compliance” malfunction, O - “Other” ELD detected malfunction, 1 - “Power data diagnostic” event, 2 - “Engine synchronization data diagnostic” event, 3 - “Missing required data elements data diagnostic” event, 4 - “Data transfer data diagnostic” event, 5 - “Unidentified driving records data diagnostic” event, 6 - “Other” ELD identified diagnostic event. The UNITY ELD Malfunction and Diagnostic Event Records list all ELD malfunctions that have occurred on UNITY ELD during the time period for which this file is generated. Active malfunctions are indicated to all drivers who may use that ELD.
User Manual:
UNITY-ELD-MANUAL.pdf
UNITY ELD
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | UNITY ELD | URS | 2.3-12 and up |
Data Transfer and Reporting Procedures
> Telematic (Web Service, Email)Malfunctions and Testing
Following option 1 of Section 4.9.1, drivers using UNITY ELD system can transfer logs data via telematics transfer methods. Through the mobile application's DOT Inspection Mode, drivers can send logs to an officer via web services or email. An in-app display of logs is also available.Certification Statement
UNITY ELD has been programmed to self-monitor for all malfunctions and data diagnostic events listed in section 4.6.1 "Compliance Self-Monitoring, Malfunctions and Data Diagnostic Events." Furthermore, active ELD malfunctions and data diagnostic statuses are indicated to the operator with a recognizable visual indication as per sections 4.6.2 and 4.6.3.
User Manual: Unity ELD - Driver Guide.pdf
