Products with ELD "J32B5K"
Below you will find a list of products with the ELD "J32B5K" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufacturer, as well as contact information for further troubleshooting.
Stargate ELD
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | Stargate ELD | LU783N | 3.0.25 and later |
Data Transfer and Reporting Procedures
> Telematic (Web Service, Email)Malfunctions and Testing
Stargate ELD supports the production and telematics transfer of ELD records through Wireless Web services and Email. To begin a transfer, select "DOT Inspection" from the menu and press the "Transfer Logs" button on the DOT Inspection page. Under Data Transfer Type, select "Web Service" to send records through Web services or "Email" to send records by Email. Submit the transfer by pressing "Confirm".Certification Statement
Stargate ELD records malfunction and data diagnostic events detected while monitoring compliance with technical requirements. Its monitoring identifies malfunctions and data inconsistencies using the standard codes below. Malfunction categories: P - Power compliance malfunction E - Engine synchronization compliance malfunction T - Timing compliance malfunction L - Positioning compliance malfunction R - Data recording compliance malfunction S - Data transfer compliance malfunction O - Other ELD-detected malfunction Diagnostic event categories: 1 - Power data diagnostic event 2 - Engine synchronization data diagnostic event 3 - Missing required data elements data diagnostic event 4 - Data transfer data diagnostic event 5 - Unidentified driving records data diagnostic event 6 - Other ELD-identified diagnostic event All malfunctions occurring on Stargate ELD during the period represented by a generated file are listed in the Stargate ELD Malfunction and Diagnostic Event Records. The device indicates active malfunctions to every driver who may use it.
User Manual:
Stargate ELD User Manual.pdf
