Products with ELD "EXP245"
Below you will find a list of products with the ELD "" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufactorer, as well as contact information for further troubleshooting.
ELD-Express
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | ELD-Express | ELDXP245 | 1 & up |
Data Transfer and Reporting Procedures
>Malfunctions and Testing
ELD-Express solution supports Option 1 (Telematics Transfer methods) of 4.9.1 of Appendix A to Subpart B of 49 CFR 395. Using the driver app, drivers can initiate a data transfer using wireless webservices or using email. Drivers can initiate a data transfer via the "one-touch" DOT Inspection button on the HOS main page. This will allow for an Officer to review logs via the the mobile display , or transfer logs via webservices or email as desiredCertification Statement
ELD Malfunctions On Logbook screen of ELD driver always sees the eld icon, if any malfunction occurs - the driver will be notified with a popup reporting information about the malfunction and suggestions on how the driver should try to resolve/fix it and eld icon will become red. Same time data about malfunction save into user history and will be displayed in inspection display/print data, eld data file. If any malfunctions are currently active - eld icon will be red and clicking on it will show current malfunctions information. Also, each eld customer will receive a printout, detailing possible malfunctions, how to identify them and steps to resolve it. If need any additional information - please provide more specific question, as nowhere in eld mandate/ELD Test Plan and Procedures specified what exactly should be pointed in this field(explanation, examples) Currently implemented malfunctions: -Power data diagnostic events - if ELD is not powered and fully functional within one minute of the vehicle’s engine receiving power -Power compliance malfunctions - if ELD is not powered for an aggregated in-motion driving time of 30 minutes or more over a 24-hour period across all driver profiles -Engine synchronization data diagnostic events - if no data comes from vehicle ecu's within five seconds of the need -Engine synchronization compliance malfunctions - if no data comes from vehicle ecu's for more than 30 minutes during a 24-hour period aggregated across all driver profiles. -Timing compliance malfunction - if ELD can no longer meet the underlying compliance requirement to record Coordinated Universal Time (UTC) -Positioning compliance malfunction - if ELD fails to acquire a valid position measurement within 5 miles of the commercial motor vehicle moving and 60 minutes has passed(gps failure) -Data recording compliance malfunction - occurs when an ELD can no longer record or retain required events or retrieve recorded logs that are not kept remotely by the motor carrier(memory limit, save failure) -Missing required data elements data diagnostic event - if any required data field is missing at the time of its recording(validation failure) -Data transfer data diagnostic event - if when the operation of the data transfer mechanism(s) is not confirmed(file generation failure, transfer failure) -Data transfer compliance malfunction - if ELD stays in the unconfirmed data transfer mode following the next three consecutive monitoring checks(file generation failure, transfer failure) -Unidentified driving records data diagnostic event - If ELD record driving event with no driver logged in for more than 30 minutes of driving time for an unidentified driver is recorded within a 24-hour period
User Manual:
ELD-Express UserManual 1.pdf
