Products with ELD "ESBLE1"
Below you will find a list of products with the ELD "ESBLE1" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufacturer, as well as contact information for further troubleshooting.
CloudELD
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | CloudELD | BLE1 | 1.0.00 |
Data Transfer and Reporting Procedures
>Malfunctions and Testing
Our product supports wireless transfer through web services and email. Instructions: 1. Click on top left menu. 2. Tap on DOT Inspection mode 3. Click on Data Transfer icon on top right corner 4. Click on Email or Web services tab. 5. Enter the comment 6. Click on Send button.Certification Statement
The ELD System support to monitor all the compliance of FMCSA for various detectable malfunctions and data diagnostic events. Power (P) - Device lost power during driving events for a total of 30 min or more, over a 24-hour period. Engine Synchronization (E) - Device lost connection to the ECM for a total of more than 30 min during a 24-hour period. Timing (T) - Device is not able to synchronize to UTC. Positioning (L) - Device is not able to acquire a valid position measurement within 5 miles of vehicle movement for a total of more than 60 min over a 24 hour period. Data recording (R) - Device is no longer able to record or retain required event data or retrieve locally-stored recorded logs. Data transfer (S) - Device continues to fail checks of the roadside transfer mechanism for three days following a Data Transfer Diagnostic Event. Other ELD detected (O) - If application has stopped working or is not responding as expected. On Home Screen top right corner if any malfunction occurs in the device icon with circle M appears and similar way if any data diagnostic events occurs icon with circle D appears.
User Manual:
CloudELD BLE User Document.pdf
CloudELD
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | CloudELD | BLE1 | 1.4 |
Data Transfer and Reporting Procedures
> Telematic (Web Service, Email)Malfunctions and Testing
Our product supports wireless transfer through web services and email. Instructions: 1. Click on top left menu. 2. Tap on DOT Inspection mode 3. Click on Data Transfer icon on top right corner 4. Click on Email or Web services tab. 5. Enter the comment 6. Click on Send button.Certification Statement
The ELD System support to monitor all the compliance of FMCSA for various detectable malfunctions and data diagnostic events. Power (P) - Device lost power during driving events for a total of 30 min or more, over a 24-hour period. Engine Synchronization (E) - Device lost connection to the ECM for a total of more than 30 min during a 24-hour period. Timing (T) - Device is not able to synchronize to UTC. Positioning (L) - Device is not able to acquire a valid position measurement within 5 miles of vehicle movement for a total of more than 60 min over a 24 hour period. Data recording (R) - Device is no longer able to record or retain required event data or retrieve locally-stored recorded logs. Data transfer (S) - Device continues to fail checks of the roadside transfer mechanism for three days following a Data Transfer Diagnostic Event. Other ELD detected (O) - If application has stopped working or is not responding as expected. On Home Screen top right corner if any malfunction occurs in the device icon with circle M appears and similar way if any data diagnostic events occurs icon with circle D appears.
User Manual: CloudELD BLE User Document.pdf
