Products with ELD "ERS174"
Below you will find a list of products with the ELD "" obtained from our database, including their available manuals, documentation, and images.
Click the corresponding vendor name to obtain additional information on the manufactorer, as well as contact information for further troubleshooting.
ELD4TRUCKING
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | ELD4TRUCKING | ERS | 2.0 or higher |
Data Transfer and Reporting Procedures
>Malfunctions and Testing
ELD4TRUCKING is capable of producing and transferring the ELD records via telematics transfer methods: Wireless Web services and Email. In order to send the ELD records via Web services, a driver must press “DOT Inspection” menu item, then press “Send Logs” button, select Web Service as the Data Transfer Type and press “SEND” button. In order to send the ELD records via Email, a driver must press “DOT Inspection” menu item, then press “Send Logs” button, select Email as the Data Transfer Type and press “SEND” button.Certification Statement
ELD4TRUCKING monitors its compliance with the technical requirements and detects malfunctions and data inconsistencies and keeps records of its malfunction and data diagnostic event detection. Following standard coding is implemented for required compliance malfunction and data diagnostic event detection: P - “Power compliance” malfunction, E - “Engine synchronization compliance” malfunction, T - “Timing compliance” malfunction, L - “Positioning compliance” malfunction, R - “Data recording compliance” malfunction, S - “Data transfer compliance” malfunction, O - “Other” ELD detected malfunction, 1 - “Power data diagnostic” event, 2 - “Engine synchronization data diagnostic” event, 3 - “Missing required data elements data diagnostic” event, 4 - “Data transfer data diagnostic” event, 5 - “Unidentified driving records data diagnostic” event, 6 - “Other” ELD identified diagnostic event. The ELD4TRUCKING Malfunction and Diagnostic Event Records list all ELD malfunctions that have occurred on ELD4TRUCKING during the time period for which this file is generated. Active malfunctions are indicated to all drivers who may use that ELD.
User Manual:
ELD4TRUCKING-MANUAL.pdf
ELD4TRUCKING
| Vendor | Device Name | Model Number | Approved Version |
|---|---|---|---|
| | ELD4TRUCKING | ERS | 2.21.32 and later |
Data Transfer and Reporting Procedures
> Telematic (Web Service, Email)Malfunctions and Testing
ELD4TRUCKING ELD software supports data transfer through telematics, meaning the driver can transfer their logs through wireless web services or email when an officer requests it. The app also enables the driver to display logs for the current shift and the previous seven consecutive days on their mobile device in case they do not have an internet connection during a roadside inspection.Certification Statement
ELD4TRUCKING has followed all necessary steps to ensure the hash feature functions properly. The hash feature is utilized to create a fixed-digit hexadecimal value to meet the requirements. ELD4TRUCKING allows cross-checking the authenticity of an ELD by adding both the “ELD Identifier” and the certificate part in the form of the provided authentication key.
User Manual: ELD4TRUCKING DRIVER GUIDE.pdf
